Name: Customized Natural White flexible T8 LED Tube Lamp Indoor 10Watt 0.6 / 0.9 / 1.2 / 1.5m
Brand: S-Tech, Lightingtalk
SKU: 108B10-X30R
Price: 1.00 USD
Availability: InStock
Rating: 4.6 (155 reviews)

Home Products T8 LED Tube Lights

Customized Natural White flexible T8 LED Tube Lamp Indoor 10Watt 0.6 / 0.9 / 1.2 / 1.5m

Product Details:

Place of Origin:	Shenzhen City, China
Brand Name:	S-Tech, Lightingtalk
Certification:	CE,C-tick, EMC, ETL, FCC, GS, LVD, PSE, RoHS, SAA,
Model Number:	108B10-X30R

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiation
Packaging Details:	Qty/CTN: 25pcs, Gross Weight: 7.2Kg
Delivery Time:	3~7 days
Payment Terms:	L/C,D/P,T/T, Western Union, cash , pay pal
Supply Ability:	100000 Piece/Pieces per Month

Contact Now

Detailed Product Description

Power:	10W	Application:	Warehouse, Indoor, Factory
Color Temperature:	Natural White	Features:	Flexible
Key Material:	Aluminum Alloy	Product Name:	T8 LED Tube
High Light:	led tube lighting , T8 led tube lights

Customized Natural White flexible T8 LED Tube Indoor 10Watt 0.6 / 0.9 / 1.2 / 1.5m

Quick Detail:

Japanese led light tube 10w with PSE ETL SAA, CE ROHS 45 ° 90° Rotatable 2ft 600mm 10W 108B10-X30R T8 LED Tube Light Fixtures

Model Number: 108B10-X30R
Item Type: 0.6m 45 ° 90° Rotatable LED T8 tube
Light Source: Epistar 3014SMD 10*30mil
Lamp Body Material: Pure Aluminum Alloy+ PC cover (94-V0)
Power: 10W
Input Voltage(V): AC 110~240V
Light efficiency: 85-100lm/w
Certification: CE,C-tick, EMC, ETL, FCC, GS, LVD, PSE, RoHS, SAA,
Service: OEM label-print
Warranty: 3years

Description:

Model Number: 108B10-X30R
Item Type: 0.6m 45 ° 90° Rotatable LED T8 tube light
Light Source: Epistar 3014SMD 10*30mil
Lamp Body Material: Pure Aluminum Alloy+ PC cover (fire-proof 94-V0, imported form Taiwan, you can choose frosted, transparent PC, the luminousness is ≥ 90%)
Power: 10W
Input Voltage: 110~240V AC
Light efficiency: 85-100lm/w
Lamp Luminous Flux: 650~950Lm
Lamp Luminous Efficiency(lm/w): 90
CRI (Ra>): 70
Color Temperature: Warm White(3000K±300K), Natural White(4000K±400K), Cold White(5700K±570K)
Working Temperature: -20℃ - 40℃
Working Lifetime: 40000hrs
IP Rating: IP33
Certification: CE,C-tick, EMC, ETL, FCC, GS, LVD, PSE, RoHS, SAA,
Service: OEM label-print
Warranty: 3years
Rotatable: 45 degree /90 degree

Applications:

Widely used in the lighting of office, hospital, school, business area, airport, metro station, flyover, signboard, Gymnasium, landmark and so on.

Specifications:

Rated Voltage	100~240VAC / 50~60 Hz
Wattage	10W*
Power Factor	>0.85
Lumen	650~950Lm*
Efficiency	>75Lm/w*
Beam Angle	≥180°
Flux(Lux)@1M	＞150Lux*
Lifespan (hrs) @25℃	40,000hrs *
Ambient Temp. (℃)	-20℃~40℃
Storage Temp. (℃)	-40℃~65℃
Color Temp.	3000K±300K, 4000K±400K, 5700K±570K
CRI	＞70%
Key Material	Aluminum Alloy+ PC Cover
N.W.(g)	190g*
Warranty	3years

Item	Wattage	CCT	Flux@1m	Lumen	Efficiency	CRI
108B10-R30R	10W	3000K±300K	165lux*	650~750lm*	>65Lm/w*	>80%
108B10-T30R	10W	4000K±400K	200lux*	780~900lm*	>78Lm/w*	>70%
108B10-W30R	10W	5700K±570K	210lux*	820~950lm*	>82lm/w*	>70%

Size:

Length A	Length B	Length C	Length D	Dia E	Dia F
602mm	595mm	588mm	44mm	Ø31.2	Ø28

Customized Natural White flexible T8 LED Tube Lamp Indoor 10Watt 0.6 / 0.9 / 1.2 / 1.5m 0

Flux Data:

Distance Item	1m	2m	3m
108B10-R30R	165 lux	39 lux	20 lux
108B10-T30R	200 lux	47 lux	24 lux
108B10-W30R	210 lux	47 lux	23 lux

Certificate Applicable:

CE Applicable standards: EN55015:2006+A12007+A2:2009

EN61547:2009

EN61000-3-2:2006+A1:2009+A2:2009

EN61000-3-3:2008

Customized Natural White flexible T8 LED Tube Lamp Indoor 10Watt 0.6 / 0.9 / 1.2 / 1.5m 1

Customized Natural White flexible T8 LED Tube Lamp Indoor 10Watt 0.6 / 0.9 / 1.2 / 1.5m 2

Packing:

Qty/CTN: 25pcs
Gross Weight: 7.2Kg
Size of Carton:
CTN A: 618×34×34mm
CTN B: 630×210×185mm

Customized Natural White flexible T8 LED Tube Lamp Indoor 10Watt 0.6 / 0.9 / 1.2 / 1.5m 3

Competitive Advantage:

＊ Structure & Material

1) We use high quality pure Aluminum Alloy, it is heavier than other supplier tube, our PC cover is fire-proof 94-V0 and imported from Taiwan.

2) PC cover has frosted, translucent, optical for you choose, the luminousness is ≥ 90%

3) The PC shell has anti-oxidation processing, not turn to Yellow within 3 years!

4)Electrolytic capacitor- Rubicon; LED- Epistar chip (Taiwan Brand); MLCC- TDK (Japanese Brand),Yageo (Taiwan Brand); MOS-UTC (Taiwan Brand)/Infineon (Germany Brand)

＊ Optics Design

1) Glare Index <19, No glare for our nice optics design

2) The lighting effect is very even (just like traditional fluorescent tube

＊ Quality Control & Lead time Control

1) Strict Materials testing & purchasing

2) Automatically production with SMT & Reflow Soldering machines

3) Strict test processing: Special Automatically Aging test line, integrating sphere test..) to warranty stable tubes ex-factory.

4) Product Reject Ratio is <2‰, we guarantee 3 years strictly!

＊ Certificate

CE,C-tick, FCC, TUV, LVD, PSE, RoHS, SAA,

CE 60cm 45 ° 90° Rotatable T8 SMD led tube light, 10W 0.6m T8 led tube lighting, 8W 3014SMD T8 led tube lamp
