| Place of Origin: | China |
| Brand Name: | FY |
| Certification: | UL CUL DLC CSA VDE CE ROHS |
| Model Number: | FY-T8-1200NX |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | usd12.2-12.9/piece |
| Packaging Details: | 25pcs/carton |
| Delivery Time: | 5~7 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Material: | Aluminum+pc | Voltage: | 85-265V AC |
|---|---|---|---|
| Wattage: | 18W | CCT: | 3000~6500K |
| Power Factore: | >0.95 | THD: | <15% |
| LED TUBE: | LED TUBE LIGHT | Lens: | Clear; Frosted, Strip |
| End Cap: | G13 | Length: | 1200mm |
Feature:
• Isolated UL approved driver inside the tube
• Unique appearance with plastic & alive end cap to guarantee the safety
• Color temperature can be offered as customer demands.3000K-6500K
• Each LED work well independently with special circuit diagram
• Above 70% energy saving over normal fluorescent tube
• No UV & Lead free component & materials used for the tube
• Environment-friendly, No Pb, No Hg
Specifications
|
Length |
|
600 |
1200mm |
1500mm |
|||||
|
Power |
|
10w |
18w |
20w |
22w |
25w |
28w |
||
|
Lumens (lm) |
Milky |
1100 |
1980 |
2200 |
2420 |
2750 |
3080 |
||
|
|
clear |
1200 |
2160 |
2400 |
2640 |
3000 |
3360 |
||
|
Lumen effcacy |
milky |
110lm/w |
|||||||
|
|
clear |
120lm/w |
|||||||
|
Power factor |
>0.95 |
||||||||
|
End cap |
G13 |
||||||||
|
Input voltage |
AC85-265V |
||||||||
|
Working Voltage |
DC36-42V |
||||||||
|
Color Index (Ra) |
3000K-6500K |
||||||||
|
Operating temperature |
-25°C~+55°C |
||||||||
|
warranty |
5 years |
||||||||
|
Certificate |
VDE/CE/RoHS/UL/CUL/DLC/LM-79/LM-80 |
||||||||
Application:
1. Warehouse
2. Production
3. Stairway
4. Basement
5. Showroom
6. Parking lot
7. Gymnasium / Tennis Court
8. School
Quality control:
1. QC in every production process
2. Great material for heat sink:
Aluminium board and Aluminium housing guarantee double heat releasing to avoid light depreciation
and prolong lifespan up to 50,000Hrs.
3. 72 hours aging test before shipment includes: 72Hrs for aging light soure, 72Hrs for aging IC,compacitor,and resistor
4. strict shaking test before shippment
high temperature test(-20°C~ 65 °C), drop testfrom the height of 1.2m in 6 directions, hi-pot test 4800Vfor 1 min and so on.
