| Place of Origin: | China(mainland) |
| Brand Name: | EGV |
| Certification: | CE,ERP,Energy Star,FCC |
| Model Number: | EGV-3012 |
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Carton box |
| Delivery Time: | 7-15 working days |
| Payment Terms: | T/T,West Union,L/C,D/A,D/P |
| Supply Ability: | 10000 pcs Per month |
| Applications: | Home | Beam Angle: | 125° |
|---|---|---|---|
| Color Temperature: | 3500k - 6500k | CRI: | 80 |
| Dimensions: | 300×1200mm | Feature: | Indoor |
| Install Ways: | Embedded | Power: | 25W |
| Product Name: | Indoor LED Lighting | Shape: | Square |
| Thickness: | 11mm | ||
| High Light: | LED Wall Lighting,Indoor LED Lighting |
||
4ft 4080Lumens Current Indoor LED Wall Lights / IP50 Commercial LED Lighting Fixtures
Quick Detail:
1.CRI:>80
2.Wattage:25W
3.Power Factor:>95%
4.IP Rate:IP50
5.Lumens:3060~4080lm
6.ODE:Yes
7.Color Temperature :3500~6500k
8.Operation Temp.:-20~50℃
9.Light Source:SMD5730
10.Beam Angle:125°
11.Life Span:>40,000
Description:
＊ Aluminum with high quality laser dotted guide panel light
＊ Super size accept customized
＊ CRI>80
＊ Beam angle is 125°
＊ Up to 80% energy saving
＊ Instant star, no flicking, no humming
＊ No RF interference
＊ Environmentally friendly, mercury and lead free
Applications:
1.Meeting room, conference room,communication office
2.office, gallery and home
3.Commercial environment, real estate, commercial building,Airport
4.Shopping mall, super market,chain shops, shops, hotel, restaurant
Specifications:
|
Model |
EGV-3030 |
EGV-3060 |
EGV-6060 |
EGV-3012 |
EGV-6012 |
|
Dimensions(mm) |
295x295mm |
295x595mm |
595x595mm |
295*1195mm |
595*1195mm |
|
Thickness(mm) |
11mm |
||||
|
Main Material |
AL+PMMA |
||||
|
Light Source |
SDM5730 |
||||
|
LED Qty(pcs) |
75/90pcs |
90/120pcs |
180/240pcs |
180/240pcs |
300/360pcs |
|
Input Voltage(v) |
AC100-277V,50-60HZ(UL);AC100-240V,50-60HZ(CE) |
||||
|
Rated Current(A) |
|
|
1A |
1.25A |
1.5A |
|
Output Voltage(v) |
|
|
27/42V |
20V |
27/42V |
|
Watts(w) |
15/18w |
18/24w |
36/48w |
36/48w |
60/72w |
|
Lumens(lm) |
1275/1530lm |
1530/2040lm |
3060/4080lm |
3060/4080lm |
5100/6120lm |
|
Power Factor |
>90% |
||||
|
Color Temperature(k) |
3500-6500k |
||||
|
Luminous Efficiency |
80-85 |
||||
|
CRI |
>80 |
||||
|
Beam Angle |
125° |
||||
|
Life Span |
>40,000h |
||||
|
Operation Temp. |
-20~50℃ |
||||
|
IP Rate |
IP50 |
||||
|
Way To Install |
Lifting,Flat,Embedded,Snap-in |
||||
